Brochures & Downloads

Resources

Find and download  brochures, data sheets and technical drawings for our Spaceshade® canopies here.

Is there anything else you're looking for? Contact us today.

brochures & data sheets

Canopies

Spaceshade Education

Spaceshade®

Solspan (4)

Solspan®

Brochures & data sheets

Cycle Shelters

Browse our range of cycle shelters and select the one that meets your needs.

Resources - Velo Cycle Shelter

Velo

Download the Velo shelter data sheet here.

Resources - Oslo Cycle Shelter

Oslo

Download the Oslo shelter data sheet here.



Resources - Soundwell Cycle Shelter

Soundwell

Download the Soundwell shelter data sheet here.

Resources - Stockholm Cycle Shelter

Stockholm

Download the Stockholm shelter data sheet here.

Drawings

Resources for Architects

Download Spaceshade® Revit files for use in your projects here.

Commercial Walkway Canopies

Spaceshade Lux

Click to download Revit Files for Spaceshade® Lux Canopies.

Spaceshade® Lux Freestanding Canopy

Spaceshade® Lux Wall-Mounted Canopy



P1002041-2 (2)

Spaceshade Max

Click to download Revit Files for Spaceshade® Max Canopies.

Spaceshade® Max Freestanding Canopy

Spaceshade® Max Wall-Mounted Canopy



Western Health Canopy 2

Sidewalls

Click to download drawings for glass or polycarbonate sidewalls, or Spaceshade® retractable blinds.

Sidewalls

Retractable blinds

FAQs

What's the difference between a wall-mounted and a freestanding canopy?

Wall-Mounted canopies are fixed to the wall of the building (as per the name) and are not self-supporting. When specifying a wall-mounted canopy, it is important to ensure that the wall supporting the structure has adequate fixing grounds in place, for example a steel beam to fix directly to, or solid masonry.

Freestanding canopies are entirely self-supporting and are the most popular choice to specify. We would recommend a freestanding canopy as it is not dependent on support from a building.

Should I specify Spaceshade Lux, or Spaceshade Max? What's the difference?

The canopy you choose to specify depends on the size of canopy required.

You can use either the Lux or the Max for unsupported projections of up to 4.3m. For projections over 4.3m and up to 6m you will need to specify the Max.

The Max is also able to achieve up to 7m spans between posts (the Lux can achieve up to 5m) which may also determine your choice of product. Overall, the Max is also able to support heavier snow loadings and is more suited to solar panels and would be our recommendation for most applications.

Are the drawings available in formats other than Revit?

We only offer interactive BIM models in Revit as this is what the majority of architects use.

However, CAD files are also available to on request.

Get in touch

Looking for more?

If you've got any queries, or looking for further information, please get in touch - we're here to help you.
